Professional testing, lean manufacturing, energy saving and high efficiency.
Ø90~130(mm）
Drilling hole diameter
2800 N.m
Rotation torque
- Related equipment
OLYX-453T Integrated DTH surface Drill Rig
OLEEK-OGYX 453T
It adopts a two-stage compression air compressor with an excellent energy efficiency ratio and a rotary head with a large torque of 2800 N.m to achieve high air pressure for rapid rock drilling. It has outstanding fuel economy performance, is more energy-efficient and environmentally friendly. Its relatively light weight and compact size make it very convenient to be transferred between construction sites and steps. It is applicable to operations such as blasting holes, presplitting holes, shock-absorbing holes and ultra-deep holes in quarries and stone mines.
| MODEL | OGYX 453T |
| WEIGHT | 13,960kg |
| DIMENSIONS(L*W*H) | 9,300*2,360*3,000mm |
| ENGINE(STANDARD) | yuchai/221kw |
| ROTATION TORQUE(MAX) | 2,800N.m |
| DRILLING HOLE DIAMETER | ф90-138 mm |
| DTH HAMMER(STANDARD) | 4″inch |
| DRILLING ROD | ф76*4000 mm |
| DIESEL TANK VOLUME | 480L |
Related Products and Accessories
Jaw Crusher and Cone Screen – TX4
TX4 is the master in the field of crawler mobile hard rock crushing and screening. It creatively integrates four major units: vibrating feeder, jaw crusher, multi-cylinder hydraulic cone crusher, and three-layer double-layer screen to achieve the crushing and screening effect of a split hard rock production line, opening a new journey of mobile hard rock crushing.
Impact crushing and screening all-in-one machine-MI350RTE
OLEEK MI-RTE series crawler mobile crushing and screening machine can realize crushing and screening operations on one crawler vehicle at the same time. It is upgraded to oil-electric dual power and equipped with PLC one-button intelligent start. It can perform primary crushing and secondary crushing. The whole machine has a wide range of applications and a high degree of intelligence.
Crawler Mobile Sand Making Plant-MV-S
OLEEK MV-S series crawler mobile sand making station, the main machine adopts new impeller and special sealing structure, low energy consumption, long life, with external power, oil-electric integration, full hydraulic three drive modes to choose from. Suitable for sand and gravel shaping or further sand making after secondary crushing, large processing capacity, good crushing particle shape.
Crawler mobile heavy screening station-MSZ2515E
OLEEK MSZ series crawler mobile heavy-duty screening station is equipped with a plate-type high-torque feeder, a first-layer heavy-duty grid screen and a 1.2-meter ultra-wide patterned belt conveyor. It can effectively carry the screening cycle of oversized materials and is suitable for special scenarios such as soil-rock separation and preliminary screening of construction waste, with particularly good results.
Crawler Mobile Screening Station-MS3618
OLEEK MS series crawler mobile screening station is equipped with a vehicle-mounted fully automatic folding belt conveyor. It has a large processing capacity and can perform fine screening of materials. It is suitable for screening finished materials after crushing various sand and gravel and construction waste. The overall transportation is flexible, durable and highly reliable.
